Allen & Heath QU5D 32 Channel Digital Mixer w/Dante

Description

Allen & Heath QU5D 32 32-Channel Digital Mixer, 96kHz FPGA Core, 17 Faders w/Dante

The Qu-5 comes equipped with 16 mic/line combo inputs, two stereo line inputs, 12 XLR outputs, two TRS outputs, and one AES3 stereo digital output. It features a 7″ capacitive touchscreen, 17 motorized faders, four channel strip layers, and eight SoftKeys. Additionally, the Qu-5 includes multiple options for recording/playback including a stereo USB-A port, 32×32 USB-C port, and SD card slot.

Allen & Heath Qu-5D Features

• 96kHz FPGA Core for high-resolution audio processing
• 36 Input Channels (32 Mono/Linkable, 2 Stereo)
• Stereo Main LR Output
• 12 Mix Buses (6 Mono/Linkable Aux, 6 Stereo Aux/Groups)
• 4 Matrix Buses (Mono/Linkable)
• 16 XLR/Jack ‘Combi’ Mic/Line Inputs
• 2 Stereo Line Inputs (each with 2 TRS connectors)
• Dedicated Talkback Input
• 12 XLR Outputs
• 2 TRS Outputs
• AES3 Stereo Digital Output
• 128×128 SLink Port for I/O expansion and system integration
• Stereo Headphone Output
• 6 Multi-FX Engines with dedicated return channels
• 7” Capacitive Touchscreen for intuitive control
• 17 Motorized 100mm Faders
• 4 Channel Strip Layers for flexible workflow
• 8 Assignable SoftKeys
• USB-A Port for stereo recording/playback and data transfer
• USB-C Audio Interface (32×32 channels) for multichannel recording/playback
• SD Card Slot (16×16 @ 96kHz, 32×32 @ 48kHz) for multitrack recording/playback
• 12V Lamp Socket for visibility in dark environments
• Configurable Footswitch Connection (single/dual)
• Customizable Chromatic Channel Meter LEDs
• 19” Rack-Mountable (optional kit available)
• IEC Power Connection with universal power supply
• RJ45 Network Port for remote control and integration
• Remote Control Support via free apps for Windows, macOS, iOS, and Android
• Dante

Allen & Heath Qu-5 Specifications

• Weight: 22 lbs
• Dimensions (HxWxD): 8.3″x17.3″x18.7″
