Yamaha StagePas 600BT Portable PA
Yamaha StagePas 600BT Portable PA - Image 2
Yamaha StagePas 600BT Portable PA - Image 3
Yamaha StagePas 600BT Portable PA - Image 4

Yamaha StagePas 600BT Portable PA

MSRP: $1,528.00

$1,099.99

SKU: YAMSTAGEPAS600BT Categories: , Tag: Brand:

Description

Yamaha StagePas 600BT

All the World’s YOUR Stage

When it comes to portable live sound solutions, it doesn’t get any better than STAGEPAS. With impressive power and sound quality, intuitive control, and a comprehensive array of flexible features, including a new Bluetooth® wireless audio streaming function, this all-in-one PA system builds on the STAGEPAS legacy of providing everything you need to transform any environment into your own personal stage.

680-watt, portable PA system with 10-channel powered mixer, two 10″ speakers, a Bluetooth® input, SPX digital reverbs, an onboard feedback suppressor and versatile EQ.

  • 680W (340W + 340W) power output
  • High quality speakers (LF:10″ woofer/ HF:1.4″ voice coil compression driver)
  • Detachable 10-channel mixer (4 mono/line + 6 mono / 3 stereo line)
  • Bluetooth® audio streaming
  • 1-Knob Master EQ™ with virtual bass boost
  • High resolution SPX digital reverbs (4 types, parameter control)
  • Onboard feedback suppressor
  • Great-sounding 3-band channel EQ
  • Switchable stereo/ mono inputs
  • Hi-Z (high impedance) inputs
  • Phantom power
  • Monitor and Subwoofer outputs
  • Optional reverb footswitch
STAGEPAS 400BT STAGEPAS 600BT
Type Powered mixer with 2 passive speakers Powered mixer with 2 passive speakers
Mixing capability Mixing channels 8 10
Input channel functions Hi-Z switch: CH4, ST/MONO switch: CH5/6-7/8 Hi-Z switch: CH4, ST/MONO switch: CH5/6-9/10
Output channel functions Feedback suppressor, 1-Knob Master EQ™ Feedback suppressor, 1-Knob Master EQ™
I/O Inputs 4 mono mic / line + 4 mono / 2 stereo line 4 mono mic / line + 6 mono / 3 stereo line
Phantom power +30V (CH1, 2) +30V (CH1, 2)
Outputs SPEAKERS OUT (L, R), MONITOR OUT (L/MONO, R), SUBWOOFER OUT (MONO) with auto HPF SPEAKERS OUT (L, R), MONITOR OUT (L/MONO, R), SUBWOOFER OUT (MONO) with auto HPF
Bluetooth Bluetooth Ver.4.1, A2DP v1.2, Maximum Range: Approx. 10 m Bluetooth Ver.4.1, A2DP v1.2, Maximum Range: Approx. 10 m
Control and others Reverb foot switch Reverb foot switch
Input Channel Function Hi-Z CH4 CH4
EQ HIGH HIGH Shelving: 8 kHz HIGH Shelving: 8 kHz
EQ LOW LOW Shelving: 100 Hz LOW Shelving: 100 Hz
EQ MID – MID peaking: 2.5 kHz
On-board processors DSP SPX digital reverb (4 program, parameter control) SPX digital reverb (4 program, parameter control)
On-board amplifiers Maximum output power @4ohms 400W (200 W + 200 W) (Dynamic), 360W (180W + 180W) (Continuous) 680W (340 W + 340 W) (Dynamic), 560W (280W + 280W) (Continuous)
Speaker type Two-way bass-relfex speakers Two-way bass-relfex speakers
Frequency range (-10dB) 55 Hz – 20 kHz 55 Hz – 20 kHz
Nominal coverage H 90° 90°
V 60° 60°
Floor Monitor Angle 50° 50°
Components LF 8″ (20 cm) cone 10″ (25 cm) cone
HF 1″ (2.54 cm) voice coil compression driver 1.4″ (3.56 cm) voice coil compression driver
Maximum output level (1m; on axis) 125 dB SPL / speaker 129 dB SPL / speaker
Power requirements 100 V – 240 V 50 Hz/60 Hz 100 V – 240 V 50 Hz/60 Hz
Power consumption 30 W (Idle), 70 W (1/8 Power) 35 W (Idle), 100 W (1/8 Power)
Pole socket 34.8-35.2 mm pole socket with StageLok™ 34.8-35.2 mm pole socket with StageLok™
Accessories Cover panel, Power cord (2m), 2 x Speaker cables (6m), 12 x Non-skid pads, 2 x Ferrite Cores, 2 x Cable ties Cover panel, Power cord (2m), 2 x Speaker cables (6m), 12 x Non-skid pads, 2 x Ferrite Cores, 2 x Cable ties
Options Yamaha BMS10A (mic stand adaptor) for mixer mount, FC5 (foot switch) for reverb ON/OFF Yamaha BMS10A (mic stand adaptor) for mixer mount, FC5 (foot switch) for reverb ON/OFF
Others Handle: 1 x Top Handle: 1 x Top
Dimensions (W x H x D) Speaker 289 x 472 x 275 mm, Mixer 308 x 180 x 116 mm Speaker 335 x 545 x 319 mm, Mixer 348 x 197 x 135 mm
Weight 18.3 kg (40.3 lbs) (2 x Speaker 7.7kg + Mixer 2.9kg) 25.6 kg (56.4 lbs) (2 x Speaker 10.9 kg + Mixer 3.8 kg)

Additional information

Weight 54 lbs
Dimensions 32 × 28 × 16 in
